Dfsk C37 Timing System

Dfsk C37 Timing System

S/N

Part Level

Code  of Part and Component

Description of Part and Component

Qty.

Identification

Applicable Model

Remark

1

02

1006213D0300

Hexagonal flange bolt of intake camshaft

2

—

—

2

02

1021700D0300

VCP
Intake VCP

1

XK-0184

—

3

02

1021060E0100

Timing chain assembly

1

XK-0394

—

4

02

1021600E0100

VCP
Exhaust VCP

1

XK-0184

—

5

02

1021200E0100

Chain guide assembly

1

XK-0394

—

6

02

Q1860612F36

  M6×12
Hexagon flange bolt M6×12

2

—

—

7

02

1021048E0100

Timing sprocket of crankshaft

1

XK-0394

—

8

02

Q5507519

7.5×19
Woodruff key 7.5×19

1

—

—

9

02

Q1860630F36

  M6×30
Hexagon flange bolt M6×30

2

—

—

10

02

1021300C0300

Hydraulic tensioner assembly

1

XK-0225

—

11

02

1021161E0100

Tensioning rail of timing chain

1

XK-0394

—

12

02

1021102C0300

Tensioning rail bolt

1

—

—
