进气系统 Intake System | |||||||
序号 S/N | 零件级别 Part Level | 零部件代号 Code of Part and Component | 零部件名称 Description of Part and Component | 数量 Qty. | 标识 Identification | 适用车型 Applicable Model | 备注 Remark |
1 | 02 | 1000106C0300 | 双头螺柱-排气歧管 Stud - exhaust manifold | 2 | — | — | |
2 | 02 | 1008100E0200A | 进气歧管部件 Intake manifold component | 1 | — | C37 | |
3 | 02 | Q1840842F36 | 六角法兰面螺栓 M8×40 Hexagon flange bolt M8×40 | 3 | — | — | |
4 | 02 | Q32008T13F19 | 六角法兰面螺母 M8 Hexagonal flange nut M8 | 2 | — | — | |
5 | 02 | 3611100B1006 | 进气温度压力传感器 intake air temperature and pressure sensor | 1 | DELPHI | — | |
6 | 02 | Q1860620F36 | 六角法兰面螺栓 M6×20 Hexagon flange bolt M6×20 | 1 | — | — | |
7 | 02 | Q1860612F36 | 六角法兰面螺栓 M6×12 Hexagon flange bolt M6×12 | 1 | — | — | |
8 | 02 | 1015171E0400 | 碳罐控制阀支架 Support bracket of carbon canister control valve | 1 | — | — | |
9 | 02 | 3600200E0100B | 节气门阀体总成 Throttle valve assembly | 1 | XK-0061 | — | |
10 | 02 | Q1840640 | 六角法兰面螺栓 M6×40 Hexagon flange bolt M6×40 | 4 | — | — | |
11 | 02 | 1000378B0900 | 线束支架 Harness bracket | 1 | — | — | |
12 | 02 | Q1840812F36 | 六角法兰面螺栓 M8×16 Hexagon flange bolt M8×16 | 4 | — | — |
进气系统(续1) Intake System (Cont’d 1) | |||||||
序号 S/N | 零件级别 Part Level | 零部件代号 Code of Part and Component | 零部件名称 Description of Part and Component | 数量 Qty. | 标识 Identification | 适用车型 Applicable Model | 备注 Remark |
13 | 02 | 101501FE0200 | 进气歧管支架Ⅰ Intake manifold support bracket I | 1 | — | C37 | |
14 | 02 | 101501GE0200 | 进气歧管支架Ⅱ Intake manifold support bracket II | 1 | — | C37 | |
15 | 02 | 3612001B0000 | 碳罐控制阀护套 Carbon canister control valve sheath | 1 | — | — | |
16 | 02 | 3612030B0000 | 碳罐控制阀 Carbon canister control valve | 1 | — | — | |
17 | 02 | Q673B12 | 钢带型弹性环箍12 Steel belted elastic hoop 12 | 2 | — | — | |
18 | 02 | 1130001E0200A | 碳罐控制阀软管Ⅰ Carbon canister control valve hose I | 1 | — | C37 |
